What Is 3D Laser Scanning?

January 13, 2022

What Is 3D Laser Scanning?


author-image

esmith |

What Is 3D Laser Scanning?

3D Laser Scanning uses cutting edge technology to build “point clouds” to create digital representations oh physical assets. With these point clouds, we are able to extract surface data from an object to build its digital twin. Digital Twins can be built from a tangible object of any size, from a coffee machine to a 50,000-square-foot warehouse and everything in between. With today’s technology, there is no project too large or small; the possibilities are limitless.



How Does It Work?

There are many different types of Laser Scanning machines to choose from. However, they all operate using similar methods. First, a scanner uses a laser beam which is reflected off an object and back to the scanner, similar to sonar or echolocation in the animal kingdom. As a result, the distance can be measured down to the millimeter as the returning signals phase shift back to the machine

Simultaneously, a mirror deflects the laser beam at a vertical angle onto the same object. When using a tripod laser scanner, the scanner rotates 360° horizontally to record horizontal angles & distances. These angles are being recorded to also capture the distance between objects.

From wearable laser scanners, tripod scanners, or drone based scanners, each job can be very different. PMC uses a variety of these options to best suit the job at hand.

Why 3D Laser Scanning?

Point clouds are obtained using non-contact & non-destructive technology, so damage to your assets is virtually impossible. As a result, Digital Twins can be optimized for historical accuracy, inspection of surfaces, and reverse engineering & part scanning. 3D Laser Scanning is the best way to obtain highly detailed information with minimal intrusion. Additionally, there is no disruption to productivity while scanning is performed.

Your Laser Scanning Experts

PMC has decades of productivity improvement experience across the globe. To learn more about PMC‘s 3D Laser Scanning Services, contact one of our experts today!

Your Partner in Productivity Improvement



Want to speak with one of our Industrial Engineering, Reality Caputre, or Simulation Experts? Contact us via the form below!
We look forward to helping you achieve your goals.
